Optional accessories
If an evaporation of solvents cannot be
avoided by procedural means, a technical
ventilation is compulsory. The ventilation
prevents the formation of a permanent
explosive atmosphere (zone 0). Its efficiency
is supervised redundantly by two flow
switches. Depending on the density, the
gases will be exhausted out of the unit
either at ceiling level or at floor level. The
air supply is effected vice-versa, at floor
level or at ceiling level, to ensure, that
the air flow covers all areas of the room.
The fan ensures a high ventilation rate.
Order No.: T9980-01 (T-Line)
X9980-01 (X-Line)
Technical ventilation
Mobile version of the test cabinet with 4
steering rollers, 2 of them lock-type with brake.
Order No.: T9930-04 (T-Line)
X9930-04 (X-Line)
Steering rollers
A 45 mm duct in the side panel allows insertion
of measuring lines and hoses into the test
room. Delivery including cover.
Order No.: T9930-01 (T-Line)
X9930-01 (X-Line)
Tubular port
The digital recorder of the X-Line is working
without any paper, and it can be equipped
with a digital interface, just like the con
troller. Due to corresponding transmitters,
recording and control can be executed in
areas being not explosion-proof.
Order No.: X9990-01 (X-Line)
Digital recorder
Optional accessories of the Safety T-Line and Safety X-Line
Equipped with the options humidification
and dehumidification, an explosion-proof
cold-heat test cabinet becomes an explosion-
proof climatic test cabinet. Humidification
of the Safety T-Line is effected by a specially
controlled ultrasonic atomizer. Humidification
of the Safety X-Line is realized by an
explosion-proof version of evaporation
humidification being installed in the test
room. A plate heat-exchanger of stainless
steel, which is optimized for this application,
effects a dehumidification by falling below
dewpoint. This combination of humidification
and dehumidification allows a wide range
of temperature/humidity combinations.
The sensor is a temperature-compensated,
capacitive sensor, which can be calibrated.
Humidification
